6061 6063 T5 T6 High Quality Aluminum Square Tube

Introduction

FAQ

Product Description

Model	A(mm)	B(mm)	C(mm)	(kg/m)	Model	A(mm)	B(mm)	C(mm)	(kg/m)
HY-K02-0.7	73	23	0.7	0.4	DS139	40	4	0.3	0.425
HY-K03-0.55	73	23	0.55	0.316	HY-DS320	50	15	2	0.661
HY-K05-1.0	73	23	1	0.509	DS331	76	16	3/2.5	1.209
F100251.5	100	25	1.5	0.992	DS410	25	21.5	2	0.46
F20301.2	30	20	1.2	0.31	DS411	25	15	2	0.39
HY-F76	76	44	2	1.257	DS412	25	11	2	0.35
HY-F60	60	30	2	1.048	DS415	35	28	4	1.19
F20301.2	30	20	1.2	0.31	HY179-20*30-1.5	30	20	1.5	0.381
HY-F110	110	50	3	2.504	HY016-20*40-1.5	40	20	1.5	0.462
HY-F180	180	60	1.8	2.306	HY016-20*40-2	40	20	2	0.605
HY-F20	30	15	1.8	0.306	F32*25-2.0	32	25	2	0.572
HY-F30	30	10	1.8	0.355	F60*40-2.5	60	40	2.5	1.28
HY-F70	70	50	3	1.854	F100*50-4.0	100	50	4	3.07
HY-F80*50-2.0	80	50	2	2.298	F120605.5	120	60	5.5	5
HY-F50*50-2.5	50	50	2.5	1.287	HY-25*2.0	25	2		0.13
HY-F20*20-2.0	20	20	2	0.39	HY-35*2.5	35	2.5		0.23
HY-F150	150	30	1.8	1.721	F25*20-0.95	25	20	0.95	0.22
HY-F120	120	40	1.5	1.276	F50*25-1.5	50	25	1.5	0.58
HY-F63	63	37	0.7	0.364	F100*50-1.5	100	50	1.5	1.19
HY-F70*20-2.0	70	20	2	0.932	F32*32-2.5	32	32	2.5	0.796
HY-F60	60	20	2	0.824	F40*25-2.5	40	25	2.5	0.81
HY-23*23	23	23	0.4	0.098	YL25-4.75	25	4.75		0.321
HY-F25	25	25	0.4	0.098	YL53-4.75	53	4.75		0.68
DS087	44	22	3	0.908	F70*50-2.0	70	50	2	1.253
DS343	30	30	2	0.607	DS455	30	26	2/3	0.702
DS023	38	30	2	0.762	LP30*2.85	30	2.85		0.231
DS557	35	24	3	0.862	LP40*2.85	40	2.85		0.308
DS002	30	12	3	0.585	LP16.45*1.16	16.45	1.16		0.052
DS017	30	22	3	0.736	LP55*6.9	55	6.9		1.028
DS387	48	30	2	0.813	HY-FG60*60-2.0	60	60	2.0	1.257
FG32*25-1.5	32	25	1.5	0.439	LP40*4	40	4		0.44
FG32*32-1.5	32	32	1.5	0.496	F25*25-2.0	25	25	2	0.5
HY-LF7.8*7.8	7.8	7.8		0.164	F35*35-2.0	35	35	2	0.72
FG100*50-2.0	100	50	2.0	1.577	F40*30-2.0	40	30	2	0.72
FG215*63-6	215	63	6	8.615	F85*15-2.0	85	15	2	1.04
F50*50-1.5	50	50	1.5	0.785	F50*50-2.0X	50	50	2	1.03
AP-03-2.0	50	50	2	1.041	F6*6	6	6		0.1
AP-03-2.8	50	50	2.8	1.433	FG20*20-1.6	20	20	1.6	0.32
HY-IAP15-1.9	75	50	1.9	1.319	FG40*40-2.0	40	40	2	0.83
HY-IAP15-2.8	75	50	2.8	1.819	FG50*25-2.0	50	25	2	0.77
FG100*30-1.5	100	30	1.5	1.04	FG75*25-2.0	75	25	2	1.04
FG20*20-1.2	20	20	1.2	0.245	FG25.4*25.4-2.5	25.4	25.4	2.5	0.621
FG25*25-1.2	25	25	1.2	0.311	FG38.1*38.1-2.5	38.1	38.1	2.5	0.965
F38*38-1.2	38	38	1.2	0.48	FG50.8*50.8-3.1	50.8	50.8	3.1	1.603
F100*45-1.2	100	45	1.2	0.93	LP60*2	60	2		0.325
FG60*30-0.75	60	30	0.75	0.361	LP68*1.5	68	1.5		0.277
FG100*50-1.1	100	50	1.1	1.01	BS-FG100*100-3.0	100	100	3	3.15
HY-F85*1.2	85	8	1.2	0.591	FG50*10	50	10	1.6	0.49
F100*20-1.2	100	20	1.2	0.768	HY-562	30	30	2.4	0.7
FG150*30-1.5	150	30	1.5	1.44	LP25*10	25	10		0.68
ICPH-04	75	50	1.15	0.768	FG75*75-2.0	75	75	2	1.583
ICPH-05	75	50	2.4/1.4	1.324	FG80*80-2.0	80	80	2	1.691
HY-AL-011	100	25	1.8	1.306	FG120*50	120	50	2	1.81
HY-AL-012	75	25	1.8	1.061	CX4777	40	20	1.2	0.37
HY-AL-013	100	25	3	1.942	CX4778	20	20	1.2	0.24
HY-30302.5	30	30	2.5	0.745	WM20*20-2.5	20	20	2.5	0.49
HY-WM90	30	30	1.5	0.438	FG50*30	50	30	1	0.42
HY-CX4777	40	20	1.6	0.49	FG50*50	50	50	1	0.53
HY-CX4778	20	20	1.6	0.32	LP18.3*30.3	30.3	18.3		1.51
HY-LP25*8	25	8		0.055	FG30*30-3	30	30	3	0.826
FG60*60-3.0	60	60	3	1.84	FG30*30-2.0	30	30	2	0.6
FG25*25-3.0	25	25	3	0.683	FG35*35-2.0	35	35	2	0.715
FG50*30-2.35	50	30	2.35	0.96	WM-FG40*40-2.0	40	40	2	0.824
F8*8	8	8		0.17	LP96-1.9	96	1.9		0.494

FAQ

1: I Need Aluminum Profiles, How Can I Contact You Quickly?

Email:huayangalu@gmail.com whatsapp/Wecha/Telephone:+8615093222866 After Receiving The Message, We Will Contact You Within 2 Hours

2: Do You Provide Samples?

Yes, We Provide Samples, Just Contact Us What Kind Of Samples You Need

3: Are You Trading Company Or Manufacturer?

We Have Our Own Factory And Many Years Of Cooperation With The Factory.

4: What Is Your Lead Time For Production?

It Takes About 10-15 Days From Mold Opening To Delivery.

5: Can I Have A Visit To Your Company Before Taking An Order?

Sure,welcome!

6: What Is Your Minimum Order Quantity?

Our Minimum Order Quantity Is 1KG.

7: What Is Your Package?

We Mainly Use Wooden Boxes, Pallets, Cartons, etc. If You Have Special Packaging Needs, We Can Also Meet Them.

8: How Can You Guarantee The Quality?

Before Mass Production,We Will Test The Mould Till Its Quality Pass. In The Production,Your Order Will Be Followed By QC During Every Step. Every Product Must Be Checked And Signed Before They Move To The Next Process. At The Same Time, We Also Welcome You Or Your Agent To Inspect The Goods Before Shipment.
